Reliable design
Minimal Downtime
OEM spare parts
Extensive service network
| APPLICATION | Drilling for blasting in quarries Dimension stone industry |
| DRILLING METHOD | DTH drilling |
| HOLE DIAMETER | 3 ½" - 5" |
| DEPTH | 15 m |
| DRILLING ANGLE | Vertical / Horizontal |
| PRIME MOVER | Power for the hydraulics taken Deck engine |
| ROTARY HEAD TORQUE | 1800 Nm |
| ROTARY HEAD SPEED | 0 - 50 rpm |
| PULL UP FORCE | 1500 kg |
| PULL DOWN FORCE | 1500 kg |
| PULL UP SPEED | 30 m/min |
| PULL DOWN SPEED | 30 m/min |
| TRAMMING SPEED | 2.5 km/hr |
| COMPRESSOR | 380 cfm - 200 psi 450 cfm - 150 psi |
| OPTIONAL ATTACHMENTS | Mines safety features Dust Collector Centralized lubrication system Dust suppression system |
